13
ENGENGLISH
ASSEMBLING AND PREPARING
(Only 42/47/55LY541*, 42/47/55LY331*,
42/47/55LY341*)
2
3
1
Stand Body
Stand Base
4 EA
M4 x L20
M4 x L14
4EA
or
M4 x L14
2EA
ὤ㨴㥄
wyv{lj{pvuGjv}ly
Torx Plus Star-Head Screws
2EA
Tighten the two of these four screws
and the two Torx screws (supplied with
TV) to secure the TV. Tighten the two
Torx screws with a Torx Bit Driver (not
supplied with TV).
To Next Page
