LG 28LY330C - RS-232 C Command Reference

59
ENGENGLISH
EXTERNAL CONTROL DEVICE SETUP
Communication Parameters
y
Baud rate: 9600 bps (UART)
y
Data length: 8 bits
y
Parity : None
y
Stop bit: 1 bit
y
Communication code: ASCII code
y
Use a crossed (reverse) cable.
Command Reference List
(Depending on Model)
COM-
MAND1
COM-
MAND2
DATA
(Hexa-
decimal)
COM-
MAND1
COM-
MAND2
DATA
(Hexa-
decimal)
01. Power k a 00 to 01
12. Remote
Control
Lock Mode
k m 00 to 01
02. Aspect Ratio k c (See p.61) 13. Balance k t 00 to 64
03. Screen Mute k d (See p.61)
14. Colour
Temperature
x u 00 to 64
04. Volume Mute k e 00 to 01
15. Energy
Saving
j q 00 to 05
05. Volume
Control
k f 00 to 64
16. Auto Con-
figuration
j u 01
06. Contrast k g 00 to 64 17. Equalize j v (See p.63)
07. Brightness k h 00 to 64
18. Tune Com-
mand
m a
(See p.63)
08. Colour k i 00 to 64
19. Programme
Add/Skip
m b 00 to 01
09. Tint k j 00 to 64 20. Key m c (See p.64)
10. Sharpness k k 00 to 32
21. Control
Back Light
m g 00 to 64
11. OSD Select k l 00 to 01
22. Input select
(Main)
x b (See p.64)
NOTE
y
During USB operations such as DivX or EMF, all commands except Power(ka) and Key(mc) are
not executed and treated as NG.
