ASSEMBLING AND PREPARING
Adjusting the angle of the TV to suit view
(Only LY541*, LY331*, LY341*)
Swivel 20 degrees to the left or right and adjust
the angle of the TV to suit your view.
20˚20˚
CAUTION
y
When adjusting the angle of the product,
watch out for your fingers.
»
Personal injury may occur if hands
or fingers are pinched. If the product
is tilted too much, it may fall, causing
damage or injury.
Attaching the TV to a desk
(Depending on model)
The TV should be attached to a desk so
it cannot be pulled in a forward/backward
direction, potentially causing injury or damaging
the product.
A type )
4-Screws
(Not supplied with TV)
Desk
Stand
NOTE
y
Screw : M5 x L (*L: Table depth + 8~10
mm)
ex) Table depth: 15 mm, Screw: M5 x 25
