LG 28LY330C - Page 36

36
ENG
ENGLISH
MAKING CONNECTIONS
(Only 22/28LY54**)
COMPONENT
IN
VOLUME
CONTROL
AUDIO IN
(COMPONENT
/ DVI)
EXTERNAL
SPEAKER
OUT
OPTICAL
DIGITAL
AUDIO OUT
RS-232C IN
(CONTROL & SERVICE)
AV
(RGB)
IN 1
ANTENNA
/ CABLE IN
DC-IN
(19V )
13/18V
700mA Max
LNB
Satellite IN
AUDIO IN
(COMPONENT
/ DVI)
HDMI
DVI OUT
AUDIO OUT
+
-
COMPONENT
IN
AUDIO
L R
VIDEO
AUDIO IN
(COMPONENT
/ DVI)
OPTICAL AUDIO IN
Digital Audio
Systerm
Blu-Ray / HD STB / HD Cable Box
/ DVD / PC
Blu-Ray / HD Cable Box / DVD
RED
RED RED
RED
BLUE
BLUE
BLUE
GREEN GREENGREEN
WHITE
RIGHT
LEFT
GND
GND
UP
DOWN
Control port for
Speaker out
(Only
Satellite Models)
