3. No Video - Digital TV
Check RF Cable
Check Tuner(TU2603)
Data, CLK, SYN, VAL
Replace Tuner(TU2603)
Recheck
Y
N
1. Check Tuner(TU2603 #5) Power (3.3V)
2. Check IC803 Output voltage(3.3V)
Replace IC803
Y
N
Check Tuner(TU2602) I2C Signal
SCL(R3735), SDA(R3736)
Check IC101
Y
N
1. Check Tuner(TU2602 #7) Power (1.8V)
2. Check IC805 Output voltage(1.8V)
Replace IC805
Y
N
