MAKING CONNECTIONS
DVI to HDMI Connection
Transmits a digital video signal from an external device to the TV. Connect the external device and the TV
with the DVI-HDMI cable as shown in the following illustration. To transmit an audio signal, connect an
audio cable.
AUDIO OUT
DVI OUT
AUDIO IN
(RGB/DVI)
1
2
/ DVI IN
(*Not Provided)
(*Not Provided)
DVD/ Blu-Ray / HD Cable Box
Choose any DVI input port to connect.
It does not matter which port you use.
