LG 32MA70HY

17
ENG
ENGLISH
USING THE MONITOR SET
Connecting to External Devices
Peripheral device connection
Connect peripheral devices to the monitor using
headphone ports.
y
Peripheral devices are sold separately.
y
Cables with angled plugs may have clear-
ance issues, use straight plugs when pos-
sible.
Angle Type Straight Type
NOTE
NOTE
y
Headphones or speakers may not work nor-
mally, depending on the server PC settings.
(sold separately)
Connecting Peripherals
USB Cable connection - PC
(32MA68HY)
The USB port on the product functions as a USB
hub.
USB IN 1
USB IN 2
USB UP
NOTE
y
The monitor's USB terminal supports USB
2.0 and high speed cables.
y
DP = DisplayPort
The cable is
Separate purchase
.
Two USB Downstream ports
Connect these ports to
a mouse, USB keyboard,
memory stick with current
spec under 100mA.
One USB Upstream port
Connect this port to the
downstream port of a com-
puter, laptop or USB moni-
tor (Your computer or USB
monitor must support USB
and have USB ports).
