LG 34WL550

LGELECTRONICSINC./MONITORDIVISION
Establish:2017/7/12
LM80BADJUSTMENTSPECIFICATION

6/11
Revision:0
LG electronics
4. TotalAssemblylineprocess

 4.1EDIDSerialNumberWrite
‐ThismodelDON’TneedtowritefullediddataforupdatetheSerialnumber.
JustwritetheS/Ndatabyusingadjustmentcommand.
Send Serial data
Send 24 byte
( EDID SN(4byte) + date (2byte) + Ascii SN(18byte) )
Read C/s of Serial data Read checksum data of 24 byte

4.2VerifyHDCPKey
CheckOSDwithagingonmodeorusingMasterSignalgeneratorwithHDCPOnandconnecttomonitorwithHDMI

4.3SetAutomaticStandbytime
a.SetAutomaticStandbytimebyadjustmentjigequipment:Europe:4H,Others:OFF
Commandset:F70001(forEurope–set4h)
  F70000(forothers–set0ff)
b.ChecktheAutomaticStandbytimesettingvaluebyadjustmentjigequipment.
Pleasecheckthevalueof0xA60xEEaddress

 Value:0x00‐OFF
0x04‐Set4H


















Automatic standby time
command 확인
