LG 42PJ350C Training Manual

105
August 2010 42PJ350 Plasma
P211, P232, P311 and P331 X Board Connector (VA Diode Check)
P211, P232, P311 and P331 X Board Connector (VA Diode Check)
On Va (Open) Y-SUS connector
removed, TCPs connected.
On Va (Open) all connectors removed,
TCPs disconnected.
On Chassis Gnd
+
-
-
+
On Chassis Gnd
On Va (0.52) Y-SUS connector
removed, TCPs connected.
On Va (Open) all connectors removed,
TCPs disconnected.
P211 Left X
P311 Right X
Va 4~5
1
1
1
1
P331
3.3V 42~44
Out
In
Va 4~5
1
1
P232
3.3V 9~11
1
1
1
1
