LG 42PJ350C Training Manual

76
August 2010 42PJ350 Plasma
Z
Z
-
-
SUS Board Component Identification
SUS Board Component Identification
P4
Z-SUS
Output
FETs
P2
VS from Y-SUS.
Error Com to
the Y-SUS
M5V from SMPS to the Y-SUS generates +18V.
M5V and 18V are routed through the Control board.
Logic Signals generated on the Control board.
Z-SUS
Waveform
Test Point
J43
P3 To Z-SUB
No IPMs
Z-Bias
VR1
Z-Bias TP
R151
Z-SUS
Waveform
Development
FETs
P/N EBR63038801
P3
No IPMs
No IPMs
P1
from
Control
