Preliminary Information 42PQ30
Left and Right X Drive (Commonly known as A
Left and Right X Drive (Commonly known as A
-
-
BUS)
BUS)
TCP IC’s shown are part of the Ribbon Cable
TCP IC
TCP IC
Warning: DO NOT attempt to run the set with the Heat Sink over the TCPs removed.
After a very short time, these ICs will begin to self destruct due to overheating.
P233 P211 P232
P331 P311
LEFT X BOARD
RIGHT X BOARD
