LG 47LB5800 - Specification; Application Range; Test Condition; Test Method

- 6 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement .
1. Application range
This specification is applied to the LED TV used LC46B
chassis.
2. Requirement for Test
Each part is tested as below without special appointment.
1) Temperature: 25 °C ± 5 °C(77 °F ± 9 °F), CST: 40 °C ± 5 °C
2) Relative Humidity: 65 % ± 10 %
3) Power Voltage : Standard input voltage(AC 100-240 V~,
50/60 Hz) Standard Voltage of each products is marked by
models.
4) Specification and performance of each parts are followed
each drawing and specification by part number in
accordance with BOM.
5) The receiver must be operated for about 5 minutes prior to
the adjustment.
3. Test method
1) Performance: LGE TV test method followed
2) Demanded other specification
- Safety : CE, IEC specification
- EMC : CE, IEC
4. Model General Specification
No. Item Specication Remarks
1 Market CHINA , HONG KONG (PAL/DTMB/
DVB-C(china only) Market)
2 Broadcasting system
1) PAL-DK
2) PAL-I
3) NTSC M
4) DTMB
5) DVB-C(china only)
DTMB (Single & Multi carrier)
3 Program coverage
1) PAL-DK:VHF/UHF 1~69, Cable:1~47
2) PAL-I: VHF/UHF 1~69, Cable:1~47
3) NTSC M : VHF/UHF 2~78, Cable:1~71
4) DTMB : 21~69
4 Receiving system
Analog : Upper Heterodyne
Digital : COFDM, QAM
► DTMB
(Carrier, Code Rate, Constellation, Frame Header, Inter-
leaving)
* HONG KONG
- MODE : 3780 , 0.4/0.6 , 4/16/64QAM , PN945 , 720
QPSK : 1/2, 2/3, 3/4, 5/6, 7/8
16-QAM : 1/2, 2/3, 3/4, 5/6, 7/8
64-QAM : 1/2, 2/3, 3/4, 5/6, 7/8
► DVB-C
- Symbolrate : 4.0Msymbols/s to 7.2Msymbols/s
- Modulation : 16QAM, 64-QAM, 128-QAM and 256-QAM
5 Video Input RCA(1EA) PAL,NTSC Not use RCA gender
6 Head phone out
RF, AV, Component, HDMI1, HDMI2,
HDMI3, USB1, USB2, USB3
7
Component Input
(1EA)
Y/Cb/Cr
Y/Pb/Pr
Hybrid Type
8 HDMI Input (3EA)
HDMI1-DTV
HDMI2-DTV
HDMI3-DTV
HDMI1: PC support(HDMI version 1.3)
Support HDCP
9 Audio Input (3EA) DVI Audio, Component/AV L/R Input
10 SPDIF out (1EA) SPDIF out
11 USB (3EA) EMF, DivX HD, For SVC (download) JPEG, MP3, DivX HD
12 Ethernet Connect(1EA) Ethernet Connect
