LG 47LB5800 - Exchange the Module; Un-Repairable Cases

To Next Page

To Previous Page

Only for training and service purposes

LGE Internal Use Only

Vertical Block

Source TAB IC Defect

Horizontal Block

Gate TAB IC Defect

Vertical Line

Source TAB IC Defect

Vertical Block

Source TAB IC Defect

Horizontal Block

Gate TAB IC Defect

Horizontal line

Gate TAB IC Defect

Horizontal Block

Gate TAB IC Defect

Appendix : Exchange the Module (2)

Un-repairable Cases

In this case please exchange the module.
