A-4
PREPARATION
PREPARATION
STAND INSTALLATION
■
Image shown may differ from your TV
When assembling the desk type stand, check whether the
bolt is fully tightened. (If not tightened fully, the product
can tilt forward after the product installation.) If you tight-
en the bolt with excessive force, the bolt can deviate from
abrasion of the tightening part of the bolt.
BACK COVER FOR WIRE
ARRANGEMENT
■
Image shown may differ from your TV.
1
2
3
Carefully place the TV screen side down on a cushioned
surface to protect the screen from damage.
Assemble the TV as shown.
Fix the 4 bolts securely using the holes in the
back of the TV.
Connect the cables as necessary.
To connect additional equipment,
see the External Equipment
Setup section.
1
Open the
Cable Management Clip
as shown.
2
Cable Management Clip
Fit the
Cable Management Clip
as shown.
3
NOTE
To Next Page
