LG 47VS20 - Connecting to HD Receiver, DVD, Camcorder, Camera, Gaming Device or VCR Player

54
ENG
ENGLISH
MAKING CONNECTIONS
Connecting to a HD receiver,
DVD, Camcorder, Camera,
Gaming Device or VCR player
ConnectaHDreceiver,DVD,orVCRplayertothe
Monitorsetandselectanappropriateinputmode.
HDMI connection
Transmitsthedigitalvideoandaudiosignalsfrom
anexternaldevicetotheMonitorset.Connectthe
externaldeviceandtheMonitorsetwiththeHDMI
cableasshownonthefollowingillustration.

UseaHighSpeedHDMI™Cable.

HighSpeedHDMI™Cablesaretestedto
carryanHDsignalupto1080pandhigher.
NOTE
DVI connection
Transmitsthedigitalvideosignalfromanexternal
devicetotheMonitorset.Connecttheexternal
deviceandtheMonitorsetwiththeDVIcableas
showninthefollowingillustration.Totransmitan
audiosignal,connectanoptionalaudiocable.
AUDIO
IN
DVI IN
IN
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
AUDIO
IN
DVI IN
IN
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
Backoftheproduct.
Backoftheproduct.
(notincluded)
(notincluded)
(notincluded)
