NOTE
Using the IR Receiver
- The image may be different according to the
model.
This allows a remote control sensor to be placed
in a custom location. Then that display can control
other displays via an RS-232C cable. Install the IR
receiver towards the front of the set.
IR Receiver cable
• When you see from the back of the set, if the
IR receiver cable does not face front, the signal
reception range may shorten.
• The IR receiver is made with a magnet.It is
detachable at the bottom (typical installation)
or back (wall installation) of the set.
• Make sure that you unplug the power cord
before connecting or removing the IR Receiver.
• Please turn off the power before removing the
cable. Connecting or removing the speaker
cable while turned on may result in no sound.
NOTE
To Next Page
