AUDIO OUTPUT
Send the TV’s audio to external audio equipment via the Digital Audio Output
(
Optical
)
port.
GG
When connecting with external audio equipments, such as ampli-
fiers or speakers, please turn the TV speakers off. (
GG
pp..5599
)
NOTE
GG
Do not look into the optical output port. Looking at the
laser beam may damage your vision.
GG
Block the SPDIF out(optical/coaxial) about the contents
with ACP(Audio Copy Protection) function.
CAUTION
Connect one end of an optical cable to the TV Digital
Audio
(
Optical
)
Output port.
Connect the other end of the optical cable to the digital
audio
(
optical
)
input on the audio equipment.
Set the “TV Speaker option - Off” in the AUDIO menu.
(
GG
pp..5599
). See the external audio equipment instruction
manual for operation.
1. How to connect
2
3
1
N
AV IN 1
O
VI)
ANTENNA/
CABLE IN
RS-232C IN
(CONTROL & SERVICE)
AUDIO
AUDIO OUT
VIDEO
MONO
( )
AUDIO
S-VIDEO
REMOTE
CONTROL IN
SERVICE
DIGITAL
AUDIO OUT
OPTICAL
1
2
DIGITAL AUDIO OUTPUT
The TV has a special signal output capability which allows you to hook up the second TV or monitor.
AV IN 1
RS-232C IN
(CONTROL & SERVICE)
AUDIO OUT
VIDEO
MONO
( )
AUDIO
S-VIDEO
CONTROL IN
VICE
OPTICAL
L R
S-VIDEOVIDEO
Connect the second TV or monitor to the TV’s
AAUUDDIIOO
OOUUTT
jacks.
See the Operating Manual of the second TV or monitor
for further details regarding that device’s input settings.
1. How to connect
GG
Component1-2, RGB-PC, HDMI1/DVI, HDMI2, DTV input
sources cannot be used for AUDIO out.
NOTE
