39
ENGLISH_index
PRODUCT SPECIFICATIONS
The product specifications below may be changed without prior notice due to upgrade of product functions.
” refers to alternating current (AC), and “ ” refers to direct current (DC).
OLED screen Screen type
Thin Film Transistor (TFT)
OLED Screen
Operating conditions Daily usage 18 hours (video)
Video signal
Maximum resolution
HDMI / DISPLAYPORT: 3840x2160 @ 30Hz
- This may not be supported on some OS or graphics card
types.
Recommended
resolution
HDMI / DISPLAYPORT: 1920x1080 @ 60Hz
- This may not be supported on some OS or graphics card
types.
Horizontal frequency HDMI/ DISPLAYPORT: 30kHz to 83kHz
Vertical frequency HDMI/ DISPLAYPORT: 56Hz to 60Hz
Synchronization Separate Sync, Digital
Input/ Output ports
USB IN(2.0) 1, USB IN(2.0) 2, HDMI™ IN, DP IN, DP OUT, LAN IN, LAN OUT, IR IN, RS-
232C IN, RS-232C OUT, AUDIO OUT, LC IN, LC OUT
Embedded battery Applied
Environmental
Conditions
Operating Temperature 0°C to 40°C (32°F to 104°F)
Operating Humidity 10% to 80%
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Storage Humidity 5% to 85%
OLED Panel Pixel Pitch 0.630mm(H) x 0.630mm(V)
Power Rated Voltage AC 100-240V ~ 50/60Hz 3.7A
Dimensions
(Width x Height x
Depth) / Weight
Display
1220.3mm x 696.8mm x 4.9mm / 6.5kg
(48.0inches x 27.4inches x 0.1inch / 14.3lbs)
Signage Box
782.8mm x 238.4mm x 34.7mm / 3.4kg
(30.8inches x 9.3inches x 1.3inches / 7.4lbs)
