MAKING CONNECTIONS
ConnectvariousexternaldevicestotheportsontheMonitorset’sbackpanel.
1
 FindanexternaldeviceyouwanttoconnecttoyourMonitorsetshownonthefollowingillustration.
2
 Checktheconnectiontypeoftheexternaldevice.
3
 Gototheappropriateillustrationandchecktheconnectiondetails.

IfyouconnectagamingdevicetotheMonitorset,usethecablesuppliedwiththegamingdevice.

Itisrecommendedyoutousetheoptionalspeakerprovided.
HD Receiver DVD VCR
USB
PC
Camcorder/Camera
Gaming device
Speaker
Memorystorage
–Seep.27
