LG 55VS20 - Component connection

55
ENG
ENGLISH
MAKING CONNECTIONS
AV(CVBS) connection
Transmitstheanalogvideoandaudiosignalsfrom
anexternaldevicetotheMonitorset.Connectthe
externaldeviceandtheMonitorsetwiththe15
pinsignaltoRCAcableasshownonthefollowing
illustration.
Component connection
Transmitstheanalogvideoandaudiosignalsfrom
anexternaldevicetotheMonitorset.Connectthe
externaldeviceandtheMonitorsetwiththe15
pinsignaltoRCAcableasshownonthefollowing
illustration.Todisplayimagesbyusingprogressive
scan,makesuretousethecomponentcable.
AUDIO
IN
AUDIO
IN
AV (CVBS)
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
PC
AUDIO
IN
AUDIO
IN
AV (CVBS)
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
PC

WhenconnectingtotheAVorComponent
portusingthesharedinterface,theportmust
matchuptotheinputsource.Otherwise,
noisemayoccur.
NOTE NOTE
Backoftheproduct.
Backoftheproduct.
(notincluded)
(notincluded)
(notincluded)
(notincluded)

ForAV(CVBS)connection,theredandblue
cablesinasharedinterfacearenotinuse.
