LG ACC96T User Manual

29
REFERENCE
❋ Designs and specifications are subject to change without notice.
GeneralCD/DVDVideo
Amplifier
Speakers
Tuner
FM
AM
[MW]
(* Depending on the sound mode
settings and the source, there
may be no sound output.)
Specifications
Power supply Refer to main label
Power consumption Refer to main label
Net Weight 3.9 kg
External dimensions (W x H x D) 430 x 57 x 295 mm
Operating conditions Temperature: 5°C to 35°C, Operation status: Horizontal
Operating humidity 5% to 85%
Laser Semiconductor laser, wavelength 650 nm
Signal system PAL 625/50, NTSC 525/60
Frequency response (audio) 150 Hz to 18 kHz
Signal-to-noise ratio (audio) More than 75 dB (1 kHz, NOP -6 dB, 20 kHz LPF/A-Filter)
Dynamic range (audio) More than 70 dB
Harmonic distortion (audio) 0.5 % (1 kHz, at 1W position) (20 kHz LPF)
Video input 1.0 V (p-p), 75 Ω, negative sync., RCA jack x 2
Video output 1.0 V (p-p), 75 Ω, negative sync., RCA jack x 1
S-video output (Y) 1.0 V (p-p), 75 Ω, negative sync., Mini DIN 4-pin x 1
(C) 0.3 V (p-p), 75 Ω
COMPONENT VIDEO OUT (Y) 1.0 V (p-p), 75 ohms, negative sync, RCA jack x 1
(Pb)/(Pr) 0.7 V (p-p), 75 ohms, RCA jack x 1
Tuning Range 87.5 - 108.0 MHz or 65.0 - 74.0 MHz, 87.5 - 108.0 MHz
Intermediate Frequency 10.7 MHz
Signal-to Noise Ratio 60 dB (Mono)
Frequency Response 140 - 8,000 Hz
Tuning Range 522 - 1,620 kHz or 520 - 1,720 kHz
Intermediate Frequency 450 kHz
Stereo mode 100W + 100W (Rated Output Power 100W, 4Ω at 1 kHz, THD 10 %)
Surround mode Front: 100W + 100W (Rated Output Power 100W, THD 10 %)
Centre*: 100W
Surround*: 100W + 100W (Rated Output Power 100W, 4Ω at 1 kHz, THD 10 %)
Subwoofer*: 200W (Rated Output Power 150W, 3Ω at 30 Hz, THD 10 %)
Inputs AV IN, MIC (OPTIONAL)
Outputs S-VIDEO, MONITOR, PHONES: (32 Ω, 1.0 V)
Front/Rear Speaker Center speaker Passive Subwoofer
(LHS-76IAS) (LHS-76IAC) (LHS-76IAW)
Type 2 Way 3 Speaker 2 Way 3 Speaker 1 Way 1 Speaker
Impedance 4 Ω 4 Ω 3 Ω
Frequency Response 80 - 18,000 Hz 80 - 18,000 Hz 40 - 1,500 Hz
Sound Pressure Level 86 dB/W (1m) 86 dB/W (1m) 82 dB/W (1m)
Rated Input Power 100 W 100 W 200 W
Max. Input Power 200 W 200 W 400 W
Net Dimensions (W x H x D) 300 x 1350 x 300 mm 500 x 160 x 155 mm 240 x 450 x 390 mm
Net Weight 5.35kg 1.73kg 10.5kg
Wireless TX Transmission Output 2.4GHz
Power Supply DC 7V
Wireless RX Power requirements Refer to label of wireless RX
Power consumption Refer to label of wireless RX
Reception Output 2.4GHz
Wireless
system
