LG ARUM072DTE5 - Outdoor Unit Specifications; 208-230 V Outdoor Units

9
Product Data
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
SPECIFICATIONS
208-230V Outdoor Units
Table 1: Single Frame 208-230V Outdoor Units.
Unit Model Number
ARUM072BTE5
6.0 Ton
ARUM096BTE5
8.0 Ton
ARUM121BTE5
10.0 Ton
ARUM144BTE5
12.0 Ton
Individual Component Model Numbers - - - -
Cooling Performance
Nominal Cooling Capacity (Btu/h)
1
72,000 96,000 120,000 144,000
Rated Cooling Capacity (Btu/h)
2
69,000 92,000 114,000 138,000
Heating Performance
Nominal Heating Capacity (Btu/h)
1
81,000 108,000 135,000 162,000
Rated Heating Capacity (Btu/h)
2
77,000 103,000 129,000 154,000
Operating Range
Cooling (°F DB) 5 to 122 5 to 122 5 to 122 5 to 122
Heating (°F WB) -13 to +61 -13 to +61 -13 to +61 -13 to +61
Synchronous — Cooling Based (°F DB) 14 to 81 14 to 81 14 to 81 14 to 81
Synchronous — Heating Based (°F WB) 14 to 61 14 to 61 14 to 61 14 to 61
Compressor
Inverter Quantity HSS DC Scroll x 1 HSS DC Scroll x 1 HSS DC Scroll x 1 HSS DC Scroll x 2
Oil/Type PVE / FVC68D PVE / FVC68D PVE / FVC68D PVE / FVC68D
Fan (Top Discharge)
Type Propeller (BLDC) Propeller (BLDC) Propeller (BLDC) Propeller (BLDC)
Motor Output (kW) x Qty. 1.5 x 1 0.9 x 2 0.9 x 2 0.9 x 2
Motor/Drive Brushless Digitally Controlled / Direct
Operating Range (RPM)
Cooling 0 - 1,000 0 - 1,150 0 - 1,150 0 - 1,150
Heating 80 - 1,000 80 - 1,150 80 - 1,150 80 - 1,150
Maximum Air Volume (CFM) 8,470 11,300 11,300 11,300
Unit Data
Refrigerant Type R410A R410A R410A R410A
Refrigerant Control/Location EEV / Indoor Unit EEV / Indoor Unit EEV / Indoor Unit EEV / Indoor Unit
Factory Charge lbs. of R410A 14.3 23.2 23.2 26.5
Max. No. Indoor Units/System
3
13 16 20 24
Sound Pressure dB(A)
4
58.0 58.0 59.0 60.0
Net Unit Weight (lbs.) 430 507 507 639
Shipping Weight (lbs.) 452 534 534 666
Communication Cables
5,6
2 x 18 2 x 18 2 x 18 2 x 18
Heat Exchanger
Material and Fin Coating Copper Tube / Aluminum Fin and Black Coated Fin™ / Hydrophilic
Rows / Fins per inch 2 / 17 2 / 17 2 / 17 3 / 17
Piping for Heat Recovery Operation
7
Liquid Line Connection (in., OD) 3/8 Braze 3/8 Braze 1/2 Braze 1/2 Braze
Low Pressure Vapor Line Connection (in., OD) 3/4 Braze 7/8 Braze 1-1/8 Braze 1-1/8 Braze
High Pressure Vapor Line Connection (in., OD) 5/8 Braze 3/4 Braze 3/4 Braze 7/8 Braze
Piping for Heat Pump Operation
7
Liquid Line Connection (in., OD) 3/8 Braze 3/8 Braze 1/2 Braze 1/2 Braze
Vapor Line Connection (in., OD) 3/4 Braze 7/8 Braze 1-1/8 Braze 1-1/8 Braze
1
Nominal capacity applied with non-ducted indoor units, and is rated 0 ft. above sea level
with 25 ft. of refrigerant line per indoor unit and a 0 ft. level difference between outdoor and
indoor units. All capacities are net with a Combination Ratio between 95–105%.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb
(DB) and 67ºF wet bulb (WB) and outdoor ambient conditions of 95ºF dry bulb (DB) and
75ºF wet bulb (WB).
Nominal heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb
(DB) and 59ºF wet bulb (WB) and outdoor ambient conditions of 47ºF dry bulb (DB) and
43ºF wet bulb (WB).
2
Rated capacity is certied under AHRI Standard 1230. See www.ahrinet.org for information.
3
The System Combination Ratio must be between 50–130%.
4
Sound pressure levels are tested in an anechoic chamber under ISO Standard 3745.
5
Communication cable between Master ODU to Slave ODU(s), and Master ODU to IDUs /
HRUs to be 18 AWG, 2-conductor, twisted, stranded, shielded. Ensure the communication
cable shield is properly grounded to the Master ODU chassis only.
Do not ground the
ODU to IDUs / HRUs communication cable at any other point. Wiring must comply with all
applicable local and national codes.
6
Power wiring is eld provided, solid or stranded, and must comply with the applicable
local and national codes. See page 19 for detailed electrical data.
7
LG requires that LATS software be used on all projects to ensure correct line sizing.
Designer must verify the shop drawing design against the as built design using LATS.
Contractor must also use LG manufactured Y-Branch and Header Kits only.
