4
ENGLISH
INSTALLATION PROCESS
The foundation must be level even
Outdoor unit foundation work
Avoid short circuits and ensure
sufficient space is allowed for service
Installation of outdoor unit
Refer to automatic addressing flowchart
Automatic addressing of indoor unit
In the final check for 24hours at 3.8 MPa(38.7 kgf/cm
2
) there
must be no drop in pressure.
Airtight test
Multiple core cable must not be used.
(suitable cable should be selected)
Electrical work
(connection circuits and drive circuits)
Make sure no gaps are left where
the insulating materials are joined
Heat insulation work
Make sure airflow is sufficient
Duct work
Adjust to downward gradient
Drain pipe work
Special attention to dryness,
cleanness and tightness
Refrigerant piping work
Check model name to
make sure the fitting
is made correctly
Installation of indoor unit
Take account of gradient
of drain piping
Sleeve and insert work
Make connection clearly between outdoor, indoor,
remote controller and option.
Preparation of contract drawings
Indicate clearly who will be responsible for switch setting.
Determination of division work
The vacuum pump used must have a capacity of reaching at least
5 torr, more than 1 hour
Vacuum drying
Recharge correctly as calculated in this manual. and record the
amount of added refrigerant
Additional charge of refrigerant
Make sure there are no gaps left between the facing materials
used on the ceiling
Fit facing panels
Run each indoor unit in turn to make sure the pipe work
has been fitted correctly
Test run adjustment
Explain the use of the system as clearly as possible to your customer and
make sure all relevant documentation is in order
Transfer to customer with explanation
Preheat the crank case with the electrical heater for more than 6 hours.
CAUTION
• The above list indicates the order in which the individual work
operations are normally carried out but this order may be varied
where local conditions warrants such change.
• The thickness of the piping should comply with the relevant
local and national regulations for the designed pressure 3.8MPa.
• Since R410A is a mixed refrigerant, the required additional
refrigerant must be charged in its liquid state.(If the refrigerant
is charged in its gaseous state, its composition changes and the
system will not work properly.)
!
CAUTION
Notes : * We can guarantee the operation only within 130%
Combination. If you want to connect more than 130%
combination, please contact us and discuss the
requirement like below.
• If the operation of indoor unit is more than 130%, the airflow is
operated as low in the all indoor units.
• The number of ( ) means the number of Max. connectable
indoor units, when the connected capacity of indoor units is in
the table above.
Combination Ratio(50~200%)
Outdoor Number Connection Ratio
Single outdoor units 200%
Double outdoor units 160%
Triple outdoor units 130%
!
OUTDOOR UNITS INFORMATION
Unit
1 Outdoor Unit
System(HP)
14 16 18 20
Model
Combination Unit
ARUN140LTE4 ARUN160LTE4 ARUN180LTE4 ARUN200LTE4
Independent Unit
ARUN140LTE4 ARUN160LTE4 ARUN180LTE4 ARUN200LTE4
Refrigerant
Precharged Amount
kg 10.5 10.5 10.5 10.5
lbs 23.1 23.1 23.1 23.1
Number of maxmum connectable indoor units 23(35) 26(40) 29(45) 32(50)
Net Weight
kg 245 × 1 245 × 1 280 × 1 280 × 1
lbs 540 × 1 540 × 1 617 × 1 617 × 1
Dimensions
(WxHxD)
mm (1,240x1,680x760) x 1 (1,240×1,680×760) × 1 (1,240×1,680×760) × 1 (1,240×1,680×760) × 1
inch
(48-13/16 × 66-5/32
× 29-29/32) x 1
(48-13/16 × 66-5/32
× 29-29/32) x 1
(48-13/16 × 66-5/32
× 29-29/32) x 1
(48-13/16 × 66-5/32
× 29-29/32) x 1
Piping Conections
mm(inch) Ø 12.7(1/2) Ø 12.7(1/2) Ø 15.88(5/8) Ø 15.88(5/8)
mm(inch) Ø 28.58(1-1/8) Ø 28.58(1-1/8) Ø 28.58(1-1/8) Ø 28.58(1-1/8)
Unit
2 Outdoor Unit
System(HP)
22 24 26 28
Model
Combination Unit
ARUN220LTE4 ARUN240LTE4 ARUN260LTE4 ARUN280LTE4
Independent Unit
ARUN120LTE4 ARUN120LTE4 ARUN140LTE4 ARUN160LTE4
ARUN100LTE4 ARUN120LTE4 ARUN120LTE4 ARUN120LTE4
Refrigerant
Precharged Amount
kg 7.5 x 2 7.5 x 2 10.5 + 7.5 10.5 + 7.5
lbs 16.5 x 2 16.5 x 2 23.1 + 16.5 23.1 + 16.5
Number of maxmum connectable indoor units 35(44) 39(48) 42(52) 45(56)
Net Weight
kg 208 x 2 208 x 2 (245 × 1) + (208 × 1) (245 × 1) + (208 × 1)
lbs 458 x 2 458 x 2 (540 × 1) + (458 × 1) 540 × 1) + (458 × 1)
Dimensions
(WxHxD)
mm (920×1,680×760) x 2 (920×1,680×760) x 2
(1,240x1,680x760) x 1
+ (920x1,680x760) x 1
(1,240×1,680×760) × 1
+ (920×1,680×760) × 1
inch
(36-7/32 × 66-5/32 ×
29-29/32) x 2
(36-7/32 × 66-5/32 ×
29-29/32) x 2
(48-13/16 × 66 -5/32 × 29 -
29/32) x 1 + (36-7/32 × 66 -
5/32 × 29-29/32) x 1
(48-13/16 × 66-5/32 × 29-
29/32) x 1 + (36-7/32 × 66-
5/32 × 29-29/32) x 1
Piping Conections
mm(inch) Ø 15.88(5/8) Ø 15.88(5/8) Ø 19.05(3/4) Ø 19.05(3/4)
mm(inch) Ø 28.58(1-1/8) Ø 34.9(1-3/8) Ø 34.9(1-3/8) Ø 34.9(1-3/8)
Unit
2 Outdoor Unit
System(HP)
30 32 34 36
Model
Combination Unit
ARUN300LTE4 ARUN320LTE4 ARUN340LTE4 ARUN360LTE4
Independent Unit
ARUN180LTE4 ARUN200LTE4 ARUN200LTE4 ARUN200LTE4
ARUN120LTE4 ARUN120LTE4 ARUN140LTE4 ARUN160LTE4
Refrigerant
Precharged Amount
kg 10.5 + 7.5 10.5 + 7.5 10.5 × 2 10.5 × 2
lbs 23.1 + 16.5 23.1 + 16.5 23.1 × 2 23.1 × 2
Number of maxmum connectable indoor units 49(60) 52(64) 55(64) 58(64)
Net Weight
kg (280 × 1) + (208 × 1) (280 × 1) + (208 × 1) (280 × 1) + (245 × 1) (280 × 1) + (245 × 1)
lbs (617 × 1) + (458 × 1) (617 × 1) + (458 × 1) (617 × 1) + (540 × 1) (617 × 1) + (540 × 1)
Dimensions
(WxHxD)
mm
(1,240×1,680×760) × 1
+ (920×1,680×760) × 1
(1,240×1,680×760) × 1
+ (920×1,680×760) × 1
(1,240×1,680×760) x 2 (1,240×1,680×760) x 2
inch
(48-13/16 × 66-5/32 × 29-
29/32) x 1 + (36-7/32 × 66-
5/32 × 29-29/32) x 1
(48-13/16 × 66-5/32 × 29-
29/32) x 1 + (36-7/32 × 66-
5/32 × 29-29/32) x 1
(48-13/16 × 66-5/32
× 29-29/32) x 2
(48-13/16 × 66-5/32 ×
29-29/32) x 2
Piping Conections
mm(inch) Ø 19.05(3/4) Ø 19.05(3/4) Ø 19.05(3/4) Ø 19.05(3/4)
mm(inch) Ø 34.9(1-3/8) Ø 34.9(1-3/8) Ø 34.9(1-3/8) Ø 41.3(1-5/8)
Unit
2 Outdoor Unit 3 Outdoor Unit
System(HP)
38 40 42 44
Model
Combination Unit
ARUN380LTE4 ARUN400LTE4 ARUN420LTE4 ARUN440LTE4
Independent Unit
ARUN200LTE4 ARUN200LTE4 ARUN180LTE4 ARUN200LTE4
ARUN180LTE4 ARUN200LTE4 ARUN140LTE4 ARUN140LTE4
ARUN100LTE4 ARUN100LTE4
Refrigerant
Precharged Amount
kg 10.5 x 2 10.5 x 2 (10.5 × 2) + 7.5 (10.5 × 2) + 7.5
lbs 23.1 x 2 23.1 x 2 (23.1 × 2) + 16.5 (23.1 × 2) + 16.5
Number of maxmum connectable indoor units 61(64) 64 64 64
Net Weight
kg 280 x 2 280 x 2 (280 × 1) + (245 x 1) + (208 × 1) (280 × 1) + (245 x 1) + (208 × 1)
lbs 617 x 2 617 x 2 (617 × 1) + (540 x 1) + (458 × 1) (617 × 1) + (540 x 1) + (458 × 1)
Dimensions
(WxHxD)
mm (1,240×1,680×760) x 2 (1,240×1,680×760) x 2
(1,240×1,680×760) × 2
+ (920×1,680×760) × 1
(1,240×1,680×760) × 2
+ (920×1,680×760) × 1
inch
(48-13/16 × 66-
5/32 × 29-29/32)
x 2
(48-13/16 × 66-
5/32 × 29-29/32)
x 2
(48-13/16 × 66-5/32 × 29-
29/32) x 2 + (36-7/32 ×
66-5/32 × 29-29/32) x 1
(48-13/16 × 66-5/32 × 29-
29/32) x 2 + (36-7/32 × 66-
5/32 × 29-29/32) x 1
Piping Conections
mm(inch) Ø 19.05(3/4) Ø 19.05(3/4) Ø 19.05(3/4) Ø 19.05(3/4)
mm(inch) Ø 41.3(1-5/8) Ø 41.3(1-5/8) Ø 41.3(1-5/8) Ø 41.3(1-5/8)
Unit
1 Outdoor Unit
System(HP)
8 10 12
Model
Combination Unit
ARUN080LTE4 ARUN100LTE4 ARUN120LTE4
Independent Unit
ARUN080LTE4 ARUN100LTE4 ARUN120LTE4
Refrigerant
Precharged Amount
kg 7.5 7.5 7.5
lbs 16.5 16.5 16.5
Number of maxmum connectable indoor units 13(20) 16(25) 20(30)
Net Weight
kg 202 x 1 208 x 1 208 x 1
lbs 445 x 1 458 x 1 458 x 1
Dimensions
(WxHxD)
mm (920×1,680×760) × 1 (920×1,680×760) × 1 (920×1,680×760) × 1
inch (36-7/32 × 66-5/32 × 29-29/32) x 1 (36-7/32 × 66-5/32 × 29-29/32) x 1 (36-7/32 × 66-5/32 × 29-29/32) x 1
Piping Conections
mm(inch) Ø 9.52(3/8) Ø 9.52(3/8) Ø 12.7(1/2)
mm(inch) Ø 19.05(3/4) Ø 22.2(7/8) Ø 28.58(1-1/8)
Power Supply : 3Ø, 380V, 60Hz or 3Ø, 380 - 415V, 50Hz
Model Name : ARUN***LTE4
