4. Specifications Inverter single
Note : O : Applie, X : Not applied, – : No relation
• Filters are optional in some specific areas.
• For Circuit Breaker Rating, please conform to local standards whenever necessary.
Models Unit
Cooling Capacity kW
Btu/h.
Heating Capacity kW
Btu/h.
Power Input Cooling/Heating W
Running Current Cooling/Heating A
Starting Current Cooling/Heating A
EER W/W
Btu/h.W
COP W/W
Power Supply Ø / V / Hz
Power Factor %
Air Flow Rate Indoor,Max m
3
/min(CFM)
Outdoor,Max m
3
/min(CFM)
Moisture Removal l/h.
Sound Level Indoor,H/M/L dB(A)±3
Outdoor,Max dB(A)±3
Refrigerant & Charge (at 7.5 m) g(oz)
Additional Refrigerant charge g/m(oz/ft)
Compressor Type
Model
Motor Type
Oil Type
Oil Charge cc
O.L.P. name
Fan(Indoor) Type
Motor Output W
Fan(Outdoor) Type
Motor Type
Motor Output W
Circuit Breaker* A
Power Supply Cable No.*mm
2
Power and Transmission Cable No.*mm
2
No.*mm
2
Piping Connections Liquid Side mm(in)
Gas Side mm(in)
Drain Hose(O.D/ I.D.) mm(in)
Dimensions Indoor (W*H*D) mm
inch
Outdoor (W*H*D) mm
inch
Net Weight Indoor kg(lbs)
Outdoor kg(lbs)
Operation Range Cooling(Outdoor) °C(°F)
Heating(Outdoor) °C(°F)
Max. Piping Length m(ft)
Max. Elevation Difference m(ft)
Tool Code(Chassis) Indoor + Outdoor
Functions Temperature Control
Plasma Filter
Prefilter(washable/anti-fungus)
Auto Clean
CHAOS Wind(Auto Wind)
Steps, Fan/Cool/Heat
Airflow Direction Control(up & Down)
Airflow Direction Control(left & right)
Remote Controller Type
Setting Temperature Cooling
Range Heating
Auto Operation (Micom Control)
Auto Changeover (Micom Control)
Self Diagnosis
Timer
Sleep Operation
Soft Dry Operation
Restart Delay(minute)
Deice Control(Defrost)
Hot Start
Jet Cool
Low Ambient Operation
Special Function
AS-W096F1G2[A09AW1 NF2] AS-W096F*G2 [A09AW* NF2]
1.30~2.70~3.50 1.30~2.70~3.50
4,436~9,210~11,942 4,436~9,210~11,942
1.30~3.50~4.20 1.30~3.50~4.20
4,436~11,940~14,330 4,436~11,940~14,330
830 / 960 830 / 960
3.8 / 4.4 3.8 / 4.4
4.5 / 5.2 4.5 / 5.2
3.3 3.3
11.1 11.1
3.7 3.7
1 / 220-240 / 50 1 / 220-240 / 50
95.0 95.0
8(283) 8(283)
26(918) 26(918)
1.2 1.2
35 / 29 / 25 / 22 35 / 29 / 25 / 22
48 48
R410A, 1,000(35.3) R410A, 1,000(35.3)
20(0.22) 20(0.22)
Rotary Rotary
5RS102XAA21 5RS102XAA21
Brushless DC Motor Brushless DC Motor
FV50S FV50S
320 320
CS-7L 115 CS-7L 115
Tubo Fan Tubo Fan
24 24
Propeller Propeller
BLDC BLDC
43 43
15 15
3*1.0 3*1.0
4*1.5 (Including Earth) 4*1.5 (Including Earth)
6.35(1/4) 6.35(1/4)
9.52(3/8) 9.52(3/8)
21.5 / 16.0(0.85 / 0.63) 21.5 / 16.0(0.85 / 0.63)
770*545*245 770*545*245
30.3*21.5*9.6 30.3*21.5*9.6
770*540*245 770*540*245
30.3*21.3*9.6 30.3*21.3*9.6
15(33) 15(33)
34(74.9) 34(74.9)
-5~43(23~109.4) -5~43(23~109.4)
-10~24(14.0~75.2) -10~24(14.0~75.2)
15(49) 15(49)
7(23) 7(23)
SF + UL SF + UL
Thermistor Thermistor
Nano Nano
OO
OO
OO
3 / 4 / 4 3 / 4 / 4
Auto Auto
Auto Auto
Wireless LCD Wireless LCD
18°C ~ 30°C18°C ~ 30°C
16°C ~ 30°C16°C ~ 30°C
--
OO
OO
24h, On/Off 24h, On/Off
OO
OO
22
OO
OO
OO
O(Logic) O(Logic)
--
