62 2008 Product Data
8. Capacity tables Cooling
8.1 Cooling Capacity
AS-W096ADR0
°CWB °CDB TC SHC PI TC SHC PI TC SHC PI
14.0 20.0
16.0 22.0
18.0 25.0
19.0 27.0
22.0 30.0
24.0 32.0
2.59 2.21 0.36 2.48 2.14 0.37 2.32 2.06 0.50
2.75 2.24 0.49 2.63 2.18 0.49 2.48 2.09 0.59
2.91 2.26 0.53 2.79 2.20 0.53 2.64 2.12 0.62
2.99 2.28 0.53 2.87 2.22 0.54 2.72 2.15 0.63
3.23 2.33 0.53 3.11 2.27 0.55 2.96 2.21 0.65
3.39 2.37 0.53 3.27 2.32 0.55 3.11 2.25 0.66
Outdoor Air Temperature : °CDB
20 25 32
Indoor Air
Temperature
°CWB °CDB TC SHC PI TC SHC PI TC SHC PI
14.0 20.0
16.0 22.0
18.0 25.0
19.0 27.0
22.0 30.0
24.0 32.0
2.25 1.99 0.56 2.16 1.93 0.62 2.10 1.86 0.60
2.41 2.03 0.64 2.31 1.97 0.66 2.25 1.91 0.63
2.57 2.06 0.65 2.47 2.01 0.67 2.41 1.94 0.63
2.64 2.08 0.65 2.55 2.03 0.68 2.49 1.97 0.63
2.88 2.14 0.68 2.78 2.10 0.69 2.72 2.04 0.64
3.04 2.19 0.70 2.94 2.15 0.70 2.88 2.09 0.65
Outdoor Air Temperature : °CDB
35 40 43
Indoor Air
Temperature
Symbol Notes
AFR : Air flow rate [m
3
/min] 1. All capacities are net, evaporator fan motor heat is deducted.
DB : Dry bulb temperature [°C] 2. Indicates nominal maximum capacity.
WB : Wet bulb temperature [°C] 3. Direct interpolation is permissible. Do not extrapolate
TC : Total capacity [kW] 4. Capacities are based on the following conditions:
SHC : Sensible capacity [kW] - Interconnecting Piping Length 7.5m
PI : Power Input [kW] - Level Difference of Zero.
(Comp.+ indoor fan motor+outdoor fan motor)
AS-W096E*H2
°CWB °CDB TC SHC PI TC SHC PI TC SHC PI
14.0 20.0
16.0 22.0
18.0 25.0
19.0 27.0
22.0 30.0
24.0 32.0
2.14 1.67 0.43 2.09 1.65 0.50 2.00 1.61 0.59
2.50 1.89 0.43 2.44 1.88 0.51 2.33 1.82 0.60
2.79 2.06 0.44 2.73 2.04 0.52 2.60 1.98 0.61
2.91 2.13 0.45 2.85 2.11 0.53 2.72 2.04 0.62
3.20 2.26 0.45 3.13 2.23 0.54 2.98 2.16 0.62
3.32 2.30 0.46 3.25 2.27 0.54 3.10 2.19 0.63
Outdoor Air Temperature : °CDB
20 25 32
Indoor Air
Temperature
°CWB °CDB TC SHC PI TC SHC PI TC SHC PI
14.0 20.0
16.0 22.0
18.0 25.0
19.0 27.0
22.0 30.0
24.0 32.0
1.94 1.58 0.62 1.86 1.54 0.66 1.82 1.52 0.68
2.26 1.78 0.63 2.17 1.74 0.67 2.12 1.71 0.69
2.52 1.93 0.64 2.43 1.88 0.68 2.37 1.85 0.70
2.64 1.99 0.65 2.54 1.94 0.69 2.48 1.91 0.71
2.89 2.10 0.66 2.79 2.05 0.70 2.72 2.01 0.72
3.00 2.13 0.67 2.89 2.07 0.71 2.83 2.03 0.73
Outdoor Air Temperature : °CDB
35 40 43
Indoor Air
Temperature
