4. Specifications Inverter single
Note : O : Applie, X : Not applied, – : No relation
• Filters are optional in some specific areas.
• For Circuit Breaker Rating, please conform to local standards whenever necessary.
Models Unit
Cooling Capacity kW
Btu/h.
Heating Capacity kW
Btu/h.
Power Input Cooling/Heating W
Running Current Cooling/Heating A
Starting Current Cooling/Heating A
EER W/W
Btu/h.W
COP W/W
Power Supply Ø / V / Hz
Power Factor %
Air Flow Rate Indoor,Max m
3
/min(CFM)
Outdoor,Max m
3
/min(CFM)
Moisture Removal l/h.
Sound Level Indoor,H/M/L dB(A)±3
Outdoor,Max dB(A)±3
Refrigerant & Charge (at 7.5 m) g(oz)
Additional Refrigerant charge g/m(oz/ft)
Compressor Type
Model
Motor Type
Oil Type
Oil Charge cc
O.L.P. name
Fan(Indoor) Type
Motor Output W
Fan(Outdoor) Type
Motor Type
Motor Output W
Circuit Breaker* A
Power Supply Cable No.*mm
2
Power and Transmission Cable No.*mm
2
No.*mm
2
Piping Connections Liquid Side mm(in)
Gas Side mm(in)
Drain Hose(O.D/ I.D.) mm(in)
Dimensions Indoor (W*H*D) mm
inch
Outdoor (W*H*D) mm
inch
Net Weight Indoor kg(lbs)
Outdoor kg(lbs)
Operation Range Cooling(Outdoor) °C(°F)
Heating(Outdoor) °C(°F)
Max. Piping Length m(ft)
Max. Elevation Difference m(ft)
Tool Code(Chassis) Indoor + Outdoor
Functions Temperature Control
Plasma Filter
Prefilter(washable/anti-fungus)
Auto Clean
CHAOS Wind(Auto Wind)
Steps, Fan/Cool/Heat
Airflow Direction Control(up & Down)
Airflow Direction Control(left & right)
Remote Controller Type
Setting Temperature Cooling
Range Heating
Auto Operation (Micom Control)
Auto Changeover (Micom Control)
Self Diagnosis
Timer
Sleep Operation
Soft Dry Operation
Restart Delay(minute)
Deice Control(Defrost)
Hot Start
Jet Cool
Low Ambient Operation
Special Function
AS-W1863*H3[C18AW* N33] AS-W1868*H1 [C18AW* N81]
1.61~5.28~5.83 1.76 ~ 5.28 ~ 5.80
5,500~18,000~19,900 6,000 ~ 18,000 ~ 19,800
1.67~6.07~6.73 1.40 ~ 6.07 ~ 6.65
5,700~20,700~23,000 4,800 ~ 20,700 ~ 22,700
1,630 / 1,890 1,640 / 1,770
7.5 / 8.5 7.3 / 8.3
7.5 / 8.5 7.3 / 8.3
3.2 3.2
11.0 11.0
3.2 3.43
1,220-240,50 1 / 220~240 / 50
94.5 98.3
14.15(499) 16(565)
42(1,483) 42(1,483)
5.2 2.1
43 / - /3 7 42 / 39 / 36
57 54
R410A, 1,200(42.3) R410A, 1,200(42.3)
20(0.22) 20(0.22)
E-SCROLL E-SCROLL
5CS130XCA03 5CS130XCC03
Brushless DC Motor BLDC
RB68A RB68A
480 480
CS-7L N120 CS-7L N120
Cross Flow Fan Cross Flow Fan
25.6 20
Propeller Propeller
AC Induction AC Induction
61 65
20 20
3*2.5 3*1.5
4*2.5(Including Earth) 4*1.5(Including Earth)
6.35(1/4) 6.35(1/4)
12.7(1/2) 12.7(1/2)
21.5 /16(0.85 / 0.63) 21.5 / 16.0(0.85 / 0.63)
1,170*315*173 1,107*299*200
46*12.4*6.8 43.6*11.8*7.9
870*655*320 870*655*320
34.3*25.8*12.6 34.3*25.8*12.6
13(28.7) 14.1(31.1)
64(141.1) 46(101.4)
-5~43(23~109.4) -5~43(23~109.4)
-10~24(14.0~75.2) -10~24(14.0~75.2)
15(49) 15(49)
7(23) 7(23)
S3 + UE S8 + UE
Thermistor Thermistor
Neo O
OO
OO
OO
3 / 4 3 / 4 / 4
Auto Auto
Auto Auto
Wireless LCD Wireless LCD
18°C ~ 30°C 18°C ~ 30°C
16°C ~ 30°C 16°C ~ 30°C
--
OO
OO
24h, On/Off 24h, On/Off
OO
OO
22
OO
OO
OO
O(Logic) O
--
