FUNCTIONAL SPECIFICATIONS AC Smart BACnet
BACnet Point List : Ventilation
One Ventilation unit has a Point List as follows.
Point
No.
Control/monitoring
Object Name
(XXX : ventilation
address)
Object
Type
Unit
Inactive Active
Text- 0 Text-1 Text-2 Text-3 Text- 4 Text- 5
1 ON/OFF (Setting)
StartStopCommand_ XXX
BO Stop Start
2 ON/OFF (Status) StartStopStatus_XXX BI Stop Run
3 Lock (Setting) LockCommand_XXX BO Permit Prohibit
4 Lock (Status) LockStatus_XXX BI Permit Prohibit
5 Filter Sign Filter Sign_XXX BI Off On
6 Filter Sign Reset
Filter Sign Reset_ XXX
BV - Reset
7
Operation Mode (Setting)
ModeCommand_XXX MO
Heat
Exchange
Auto Normal
8 Operation Mode (Status) ModeStatus_XXX MI
Heat
Exchange
Auto Normal
9 - -
10 - -
11 Fan Speed (Setting)
FanSpeedCommand_ XXX
MO Low High
Super
High
Auto
12 Fan Speed (Status)
FanSpeedStatus_ XXX
MI Low High
Super
High
Auto
13 - -
14 - -
15 Alarm Alarm_XXX BI Off On
