BACnet Point List : AHU
One AHU unit has a Point List as follows.
Point
No.
Control/
monitoring
Object Name
(XXX : AHU address)
Object
Type
Unit
Inactive Active
Text- 0 Text-1 Text-2 Text- 3 Text- 4 Text-5
1 ON/OFF (Setting) StartStopCommand_XXX BO Stop Run
2 ON/OFF (Status) StartStopStatus_XXX BI Stop Run
3 Lock (Setting) LockCommand_XXX BO Permit Prohibit
4 Lock (Status) LockStatus_XXX BI Permit Prohibit
5 Filter Sign Filter Sign_XXX BI Off On 6 Filter Sign Reset Filter Sign Reset_XXX BV - Reset 7
Operation Mode (Setting)
ModeCommand_XXX MO Cool Dry Fan Heat
8
Operation Mode (Status)
ModeStatus_XXX MI Cool Dry Fan Heat
9 - -
10 - -
11 - -
12 - - 13
Set Room Temperature
SetRoomTemp _X X X AV °C
14
Room Temperature
RoomTemp _ X XX AI °C
15 Alarm Alarm_XXX BI Normal Abnormal
16 Error Code MalfunctionCode_XXX AI Reference LG Original Error Code
