LG BACnet Touch - Page 42

34
ENGLISH
FUNCTIONAL SPECIFICATIONS AC Smart BACnet
Point
No.
Control/monitoring
Object Name
(XXX : AHU address)
Object
Type
Unit
Inactive Active
Text- 0 Text-1 Text-2 Text-3 Text- 4 Text- 5
17 - -
18 - -
19 Set Temperature (Status) SetTempStatus_XXX AI °C
20 Emergency Sensor (Setting)
EmergencySensorCommand_ XXX
BO
Stop
Run
21 Emergency Sensor (Status)
EmergencySensorStatus_ XXX
BI
Stop
Run
22 Set Humidify (Setting) SetHumidifyCommand_XXX AV 40~60
23 Set Humidify (Status) SetHumidifyStatus_XXX AI 40~60
24 Humidify (Setting) HumidifyCommand_XXX BO
Stop
Run
25 Humidify (Status) HumidifyStatus_XXX BI
Stop
Run
26 Auto Ventilation (Setting) AutoVentilCommand_XXX BO
Stop
Run
27 Auto Ventilation (Status) AutoVentilStatus_XXX BI
Stop
Run
28 Supply Temperature (Status) SupplyTempStatus_ X XX AI
-127~127
29 Outdoor Temperature (Status) OutdoorTempStatus_XXX AI
-127~127
30 Mix Temperature (Status) MixTempSt atus _ X X X AI
-127~127
31 Supply Humidity (Status) SuppyHumidifyStatus_XXX AI 30~90
32 Outdoor Humidity (Status) OutdoorHumidifyStatus_XXX AI 30~90
33 Ventilation Humidity (Status) VentilHumidifyStatus_XXX AI 30~90
34 CO
2
Value (Status) CO2ValueStatus_XXX AI
0~255 (Real Value = Value*10, Example : In case Value is 20, CO
2
is 20*10=200ppm)
35 Humidify Unit (Status) HumidifyUnitStatus_XXX BI
Stop
Run
36 Heater Unit (Status) HeaterUnitStatus_XXX BI
Stop
Run
