FUNCTIONAL SPECIFICATIONS AC Smart BACnet
Point
No.
Control/
monitoring
Object Name
(XXX : AHU address)
Object
Type
Unit
Inactive Active
Text- 0 Text-1 Text-2 Text-3 Text- 4 Text- 5
37
Ventilation FAN (Status)
VentilFANStatus_XXX BI
Stop Run
38
Supply FAN (Status)
SupplyFANStatus_XXX BI
Stop Run
39
Current OA Damper (Status)
CurOADamperStatus_XXX AI 0~90
40
Current EA Damper (Status)
CurEADamperStatus_XXX AI 0~90
41
Current MIX Damper (Status)
CurMixDamperStatus_XXX AI 0~90
42
Cool OA Damper (Setting)
OADamperCoolCommand_ XXX
AV 0~90
43
Cool OA Damper (Status)
OADamperCoolStatus_XXX AI 0~90
44
Cool EA Damper (Setting)
EADamperCoolCommand_ XXX
AV 0~90
45
Cool EA Damper (Status)
EADamperCoolStatus_XXX AI 0~90
46
Cool MIX Damper (Setting)
MixDamperCoolCommand_ XXX
AV 0~90
47
Cool MIX Damper (Status)
MixDamperCoolStatus_XXX AI 0~90
48
Heat OA Damper (Setting)
OADamperHeatCommand_ XXX
AV 0~90
