FUNCTIONAL SPECIFICATIONS AC Smart BACnet
Point
No.
Control/
monitoring
Object Name
(XXX : AHU address)
Object
Type
Unit
Inactive Active
Text- 0 Text-1 Text-2 Text-3 Text- 4 Text- 5
49
Heat OA Damper (Status)
OADamperHeatStatus_XXX AI 0~90
50
Heat EA Damper (Setting)
EADamperHeatCommand_ XXX
AV 0~90
51
Heat EA Damper (Status)
EADamperHeatStatus_XXX AI 0~90
52
Heat MIX Damper (Setting)
MixDamperHeatCommand_ XXX
AV 0~90
53
Heat MIX Damper (Status)
MixDamperHeatStatus_XXX AI 0~90
54
Fan OA Damper (Setting)
OADamperFANCommand_ XXX
AV 0~90
55
Fan OA Damper (Status)
OADamperFANStatus_XXX AI 0~90
56
Fan EA Damper (Setting)
EADamperFANCommand_ XXX
AV 0~90
57
Fan EA Damper (Status)
EADamperFANStatus_XXX AI 0~90
58
Fan MIX Damper (Setting)
MixDamperFANCommand_ XXX
AV 0~90
59
Fan MIX Damper (Status)
MixDamperFANStatus_XXX AI 0~90
