FUNCTIONAL SPECIFICATIONS AC Smart BACnet
BACnet Point List : ODU
One ODU unit has a Point List as follows.
AC Smart BACnet ODU Point List may not be supported depending on the product.
If an ODU system has two or more outdoor units then the point list of only the master unit is supported
- not any of the slave units.
Some points may display only zero (0) value depending on the ODU product model.
Point
No.
Control/monitoring
Object Name
(XXX : ODU
address)
Object
Type
Unit
Inactive Active
Text- 0 Text-1
Text-2 Text-3 Text- 4 Text-5
1
Compressor Operation Status
CompOperStatus_ XXX
BI Stop Run
2 Refrigent Type RefrigentType_XXX MI R407C
422 R410A
3 Inverter Fan 1 frequency
InverterFanFreq_ XXX
AI -
4 High Pressure HighPressure_XXX AI - 5 Low Pressure LowPressure_XXX AI - 6 Sunction Temperature SunctionTemp_XXX AI
℃
7 Liquid Pipe Temperature LiquidPipeTemp_XXX AI
℃
8
Heat Exchanger Temperature
HexTemp _X X X AI
℃
9 Outdoor EEV OutdoorEEV_XXX AI -
10 Subcool EEV SubCoolEEV_XXX AI -
11 Hot Gas Valve HotgasValue_XXX BI
Stop
Run
12
InverterDischarge Temperature
InverterDischarge
Temp_XXX
AI
℃
13 Outdoor Temperature OutdoorTemp_XXX AI
℃
14 Operation Mode OperationMode_XXX MI
Stop Cool Heat
