FUNCTIONAL SPECIFICATIONS AC Smart BACnet
BACnet Point List : AWHP
One AWHP unit has a Point List as follows.
Point
No.
Control/monitoring
Object Name
(XXX : AWHP address)
Object
Type
Unit
Inactive Active
Text- 0 Text-1
Text-2 Text-3 Text- 4 Text-5
1 Run/Stop (setting) StartStopCommand_XXX BO Stop Run 2 Run/Stop (status) StartStopStatus_XXX BI Stop Run 3 Lock (setting) LockCommand_XXX BO Stop Run 4 Lock (status) LockStatus_XXX BI Stop Run 5 Operation Mode (setting) ModeCommand_XXX MO Cool
Heat Auto
6 Operation Mode (status) ModeStatus_XXX MI Cool
Heat Auto
7
Set Room Temperature (setting)
SetRoomTempCommand_ XXX
AO
8
Set Room Temperature (status)
SetRoomTempStatus_ XXX
AI
9
Set Hot Water Temperature (setting)
SetHotWaterTemp Command_XXX
AO
10
Set Hot Water Temperature (status)
SetHotWaterTempStatus_ XXX
AI
11
Set PipeOut Water Temperature (setting)
SetPipeOutWater Temp Command_XXX
AO
12
Set PipeOut Water Temperature (status)
SetPipeOutWater TempStatus_XXX
AI
