FUNCTIONAL SPECIFICATIONS AC Smart BACnet
Modbus Point List : Indoor Unit
Function Code : 0x01 and 0x05
Register Function Name
Object Name
(XXX : Unit address)
Inactive Active
1
Read
Single
Coil
ON/OFF StartStopStatus_XXX Stop Run
2 SWING SwingStatus_XXX Permit Prohibit 3 LOCK LockStatus_XXX Permit Prohibit 4 MODE LOCK ModeLockStatus_XXX Permit Prohibit 5 FAN LOCK WindFlowLockStatus_XXX Permit Prohibit 6 TEMP LOCK SetTempStatus-XXX Permit Prohibit 7 ALARM Alarm_XXX Normal Abnormal 1
Write Single
Coil
ON/OFF StartStopCommand_XXX Stop Run
2 SWING SwingCommand_XXX Permit Prohibit 3 LOCK LockCommand_XXX Permit Prohibit 4 MODE LOCK ModeLockCommand_XXX Permit Prohibit 5 FAN LOCK WindFlowLockCommand_XXX Permit Prohibit 6 TEMP LOCK SetTempCommand-XXX Permit Prohibit
