LG BACnet Touch - Page 55

47
ENGLISH
FUNCTIONAL SPECIFICATIONS AC Smart BACnet
Function Code : 0x03 and 0x06
Register Function Name
Object Name
(XXX : Unit address)
Text- 0 Text-1 Text-2 Text-3 Text- 4 Text- 5
1
Read
Holding
Registers
OPERATION MODE
ModeStatus_XXX Cool Dry Fan Auto Heat
2 FAN SPEED FanSpeedStatus_XXX Low
Middle
High Auto
3
SET ROOM TEMPERATURE
SetTempStatus_XXX °C
4 UP_SETTEMP
SetUpperTemp
Status_XXX
°C
5 LO_SETTEMP
SetLowerTemp
Status_XXX
°C
6
ROOM TEMPERATURE
RoomTemp _ X XX °C
7 ERROR CODE MalfunctionCode_XXX Reference LG original Error Code
1
Write Single
Registers
OPERATION MODE
ModeCommand_XXX Cool Dry Fan Auto Heat
2 FAN SPEED
FanSpeed
Command_XXX
Low
Middle
High Auto
3
SET ROOM TEMPERATURE
SetTemp
Command_XXX
°C
4 UP_SETTEMP
SetUpperTemp
Command_XXX
°C
5 LO_SETTEMP
SetLowerTemp
Command_XXX
°C
