86 Appendix
Appendix
7
Specifi cations
General
Power requirements:
AC 120 V ~, 60 Hz
Power consumption:
20 W
Dimensions (W x H x D):
Approx. 430 x 44 x 204 mm
(16.9 x 1.7 x 8.0 inches) without foot
Net Weight (Approx.):
2 kg (4.4 lbs)
Operating temperature:
5 °C to 35 °C (41 °F to 95 °F)
Operating humidity:
5 % to 90 %
Outputs
VIDEO OUT:
1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1
COMPONENT VIDEO OUT:
(Y) 1.0 V (p-p), 75 Ω, sync negative,
RCA jack x 1,
(Pb)/(Pr) 0.7 V (p-p), 75 Ω, RCA jack x 2
HDMI OUT (video/audio):
19 pin (HDMI standard, Type A, Version 1.3)
ANALOG AUDIO OUT:
2.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R) x 1
DIGITAL OUT (COAXIAL):
0.5 V (p-p), 75 Ω, RCA jack x 1
System
Laser:
Semiconductor laser
wavelength:
405 nm / 650 nm
Signal system:
Standard NTSC color TV system
Frequency response:
20 Hz to 20 kHz
(48 kHz, 96 kHz, 192 kHz sampling)
Signal-to-noise ratio:
More than 100 dB
(ANALOG OUT connectors only)
Harmonic distortion:
Less than 0.008%
Dynamic range:
More than 95 dB
LAN port:
Ethernet jack x 1, 10BASE-T/100BASE-TX
Bus Power Supply (USB):
DC 5 V
500 mA
• Design and speci cations are subject to
change without notice.
