Appendix 63
Appendix
6
Specifications
General
Power requirements Refer to main label on the rear panel.
Power consumption 12 W
Dimensions (W x H x D) Approx. 360 mm x 39.5 mm X 199 mm
Net Weight (Approx.) 1.4 kg
Operating temperature 5 °C to 35 °C
Operating humidity 5 % to 90 %
Outputs
HDMI OUT (video/audio) 19 pin (Type A, HDMI™ Connector)
DIGITAL AUDIO OUT (COAXIAL) 0.5 V (p-p), 75 Ω, RCA jack x 1
System
Laser Semiconductor laser
wavelength 405 nm / 650 nm
Signal system Standard PAL/NTSC colour TV system
LAN port Ethernet jack x 1, 10BASE-T / 100BASE-TX
Bus Power Supply (USB) DC 5 V
0
500 mA
y
Design and specications are subject to change without notice.
