Appendices
Modes Resolution
V-Sync
(Hz)
H-Sync
(kHz)
WXGA 1280 x 768 60 47.78
1280 x 768 75 60.29
1280 x 768 85 68.63
1280 x 720 60 44.80
1280 x 800 60 49.60
1440 x 900 60 55.90
1680 x 1050 60 65.30
1366 x 768 60 47.71
*1920 x 1080-RB 60 66.60

HDMI - Extended Wide timing
“*” Only support
1080P@60Hz (with
reduced blanking tim-
ing).
N
o
t
e
Modes Resolution
V-Sync
(Hz)
H-Sync
(kHz)
480i 720 x 480(1440 x 480) 59.94(29.97) 27.00
480p 720 x 480 59.94 31.47
576i 720 x 576(1440 x 576) 50(25) 27.00
576p 720 x 576 50 31.25
720p 1280 x 720 60 45.00
720p 1280 x 720 50 37.50
1080i 1920 x 1080 60(30) 33.75
1080i 1920 x 1080 50(25) 33.75
1080p 1920 x 1080 60 67.50
1080p 1920 x 1080 50 56.26
1080p 1920 x 1080 24 27.00
1080p 1920 x 1080 23.98 26.97

HDMI - Video Signal
