LG CMS9540F - General Specifications

Appendix 37
Appendix
5
General specifications
General
Power requirements Refer to the main label.
Power consumption Refer to the main label.
Dimensions (W x H x D) (290 x 349 x 370) mm
Net Weight (Approx.) 5.9 kg
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 60 %
Bus Power Supply 5 V
0
500 mA
Inputs
AUX IN 2.0 Vrms (1 kHz, 0 dB), 600 , RCA jack (L, R)
PORT. IN 1.2 Vrms (3.5 mm stereo jack)
MIC 20 mV
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
CD
Frequency Response 40 to 20 000 Hz
Signal-to-noise ratio 75 dB
Dynamic range 80 dB
Amplier
Stereo mode 385 W x 2 (THD 20 %)
Surround
mode
Front 385 W x 2 (THD 20 %)
Surround 380 W x 2 (THD 20 %)
Subwoofer 385 W x 2 (THD 20 %)
y
Design and specications are subject to change without notice.
