18
8
Anchor the charging station to the wall with the
stand anchoring screw j.
9
Plug the power cord into the power outlet.
Use double-sided tape
Use double-sided tape to attach the wall anchoring
block a to the charging station and the wall.
• Do not use double-sided tape on wallpaper.
• Remove the center section of double-sided
tape. Attach the wall anchoring block to the
charging station by using the tape.
• Attach the second piece of double-sided tape
to the other side of the wall anchoring block,
and use it to temporarily anchor the charging
station to the wall in the desired location.
Wall-Mounted Installation
For wall-mounted installations, the charging station
must be attached securely to the wall using the
provided (short) wall anchoring screws.
1
Connect the power adapter to the port on the
back of the charging station.
2
Before drilling, make sure that there are no
pipes or electrical wires inside the wall at the
desired location.
3
Hold the charging station at least 1 m from the
floor and near enough to easily reach a power
outlet. Mark the positions of the screw holes
on the wall.
4
Drill 2 holes at the marked positions and insert
the drywall anchor.
• Before drilling, make sure that there are no
pipes or electrical wires inside the wall at
the desired location.
• For drywall anchor: use 6.5 mm drill bit
• Recommended diameter of hole: 6.5 mm
• Recommended depth: 60 mm
• If screwing into drywall, the drywall anchor
should be used.
1m
