- 19 -- 19 -
6. Tub sub Assembly
1) Top Frame
Remove bottom 4 screws.
Remove side 2 screws.
Lift up top frame.
2) Balance Weight
Remove rear 4 screws.
Lift up balance weight.
Lift tub assembly upward.
(Be sure water softner is not blocked.)
Be careful not to be injured or scratch
floor by the sharp edge of tub.
7. Air Guide Assembly
Lift it upward to disconnect from Water
Softner.
Disconnect the wiring connection.
Remove 3 hoses assembly.
Be careful the o-ring should not be lost.
Be careful not to wet the floor by the
water left in the hose.
To Next Page
