USING THE MONITOR SET
USING THE MONITOR SET
Connecting the Monitor to
the Computer
y
This monitor supports the *Plug and Play
feature.
*Plug and Play: A feature that allows you to
add a device to your computer, without having
to reconfigure anything or install any manual
drivers.
D-SUB connection
Transmits the analog video signal from your PC
to the Monitor set. Connect the monitor to the PC
using the provided 15-pin D-SUB signal cable as
illustrated below.
y
There may be compatibility issues if an HDMI
signal is used in the PC environment.
y
Apple Adapter
An Apple adapter is required to use the
monitor with an Apple computer. The adapt-
er can be purchased at an Apple store.
NOTE
DVI-D connection
Transmits the digital video signal from your PC to
the Monitor set. Connect the PC and the monitor
with the DVI cable as shown in the following illus-
trations.
HDMI connection
Transmits the digital video and audio signals from
your PC and A/V devices to the monitor. Connect
the PC and A/V devices to the monitor with the
HDMI cable as shown in the following illustrations.
NOTE
