3-31
opyright © 2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Power Line of Main
PCB is short.
Replace the IC102
Is the IC102 normal?
YES
NO
Replace the D947
Is the D947 Normal?
YES
NO
Replace the D949
Is the D949 Normal?
YES
NO
Replace the D940
Is the D940 Normal?
YES
NO
Replace the D943
Is the D943 Normal?
YES
NO
Replace the D941
Is the D941 Normal?
YES
NO
