LG FLATRON E2350V User Manual

TIMING CHART
A
B
C
D
E
F
Video
Sync
MODE
H / V
Sync
Polarity
Dot
Clock
Frequency
Total
Period
( E )
Video
Active
Time ( A )
Sync
Duration
( D )
Front
Porch
( C )
Blanking
Time
( B )
Resolution
H(Pixels) - 31.468 900 720 18 108 54
1
V(Lines) +
28.321
70.08 449 400 12 2 35
720X400
H(Pixels) - 31.
469 800 640 16 96 48
2
V(Lines) -
25.175
59.94 525 480 10 2 33
640x480
H(Pixels) - 37.
5 840 640 16 64 120
3
V(Lines) -
31.5
75 500 480 1 3 16
640x480
H(Pixels) + 37
.879 1056 800 40 128 88
4
V(Lines) +
4
0.0
60.317 628 600 1 4 23
800x600
H(Pixels) + 46
.875 1056 800 16 80 160
5
V(Lines) +
49
.5
75.0 625 600 1 3 21
800x600
H(Pixels) - 48.
363 1344 1024 24 136 160
6
V(Lines) -
65.
0
60.0 806 768 3 6 29
1024x768
H(Pixels) - 60.
123 1312 1024 16 96 176
7
V(Lines) -
78
.75
75.029 800 768 1 3 28
1024x768
H(Pixels) +/- 67
.500 1600
1152 64 128 256
8
V(Lines) +/-
108.0
75.000
900 864 1 3 32
1152x864
H(Pixels) + 63
.981 1688 1280 48 112 248
9
V(Lines) +
10
8.0
60.02 1066
1024 1 3 38
1280x1024
H(Pixe
ls) + 79
.976 1688 1280 16 144 248
10
V(Lines) +
1
35.0
75.035 106
6 1024 1 3 38
1280x1024
H(Pi
xels) -
11
V(L
ines) +
H(Pixel
s) -
65.290 2240 1680 104 176 280
12
V(Lines)
+
14
6.25
59.954 108
9 1050 3 6 30
60 1125 1080 4
5 36
1680x1050
148.50
67.5
0 2200 1920 88 44 148 1920x1080
- 8 -
Copyright 2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
