LG Flatron M1717A Service Manual

- 2 -
CONTENTS
SPECIFICATIONS
SPECIFICATIONS ................................................... 2
PRECAUTIONS ....................................................... 3
SERVICE PRECAUTIONS ...................................... 4
TIMING CHART ....................................................... 7
DISASSEMBLY ....................................................... 8
BLOCK DIAGRAM ................................................... 9
DESCRIPTION OF BLOCK DIAGRAM ................. 11
ADJUSTMENT ...................................................... 12
TROUBLESHOOTING GUIDE .............................. 15
WIRING DIAGRAM ............................................... 19
EXPLODED VIEW...................................................20
REPLACEMENT PARTS LIST ...............................22
SCHEMATIC DIAGRAM......................................... 28
1. LCD CHARACTERISTICS
Type : TFT Color LCD Module
Active Video Area : 17.0 inch-M1717A
: 19.0 inch-M1917A
Size : 358.5(V) x 296.5(H) x 17(D)-M1717A
:
396.0(V) x 324.0(H) x 16.5(D)-M1917A
Pixel Pitch : 0.264mm x 0.264mm-M1717A
:
0.098mm x RGBmm x 0.294mm-M1917A
Color Depth : 6Bits with FRC, 16,777,216 colors
Surface Treatment : Anti-Glare(HAZE 3%), Hard Coating (3H)
Operating Mode : Normally white
Backlight Unit : 4CCFL
Electrical Interface : LVDS
2. OPTICAL CHARACTERISTICS
2-1. Viewing Angle by Contrast Ratio ≥ 10
Left : -60° min., -70° typ / Right : +60° min., +70° typ
Top : +60° min., +75° typ / Bottom : -50° min., -65° typ
2-2. Luminance : 200(min.), 250(typ.)
2-3 Contrast Ratio : 300(min.), 550(typ.)
3. SIGNAL (Refer to the Timing Chart)
3-1. Analog Video Input
1) Video Input Range : 0~0.7V ± 5%
2) Video Termination Impedance : 75Ω ±5%
3) Sync Type : Separate Sync.
4) Sync Level : TTL Low ≤ 0.8V, High ≥ 2.0V
3-2. Operating Frequency
Horizontal : 30 ~ 70kHz
Vertical : 56 ~ 75Hz
4. RESOLUTION
Analog Max : 1280 x 1024@60Hz
5. POWER SUPPLY
5-1. Power
AC 100-240Vac, 50/60Hz
5-2. Power Consumption
6. ENVIRONMENT
5-1. Operating Temperature : 10°C ~ 35°C
5-2. Operating Humidity : 20% ~ 80%
5-3. MTBF : 50,000 Hours (Min)
7. DIMENSIONS (with TILT/SWIVEL)
M1717A
Width : 389.5 mm (15.33'')
Depth : 232 mm (9.13'')
Height : 437.9 mm (17.24'')
M1917A
Width : 443.6 mm (17.46'')
Depth : 232 mm (9.13'')
Height : 475.6 mm (18.72'')
8. WEIGHT (with TILT/SWIVEL)
M1717A
Net. Weight : 5.28 kg (11.64 lbs)
Gross Weight : 6.84 kg (15.08 lbs)
M1917A
Net. Weight : 6.0 kg (13.23 lbs)
Gross Weight : 7.87 kg (17.35 lbs)
H/V SYNC
ON/ON
OFF/ON
ON/OFF
OFF/OFF
-
MODE
POWER ON (NORMAL)
SLEEP MODE
POWER S/W OFF
VIDEO
ACTIVE
OFF
OFF
POWER CONSUMPTION
less than 45 W
less than 1 W
less than 1 W
LED COLOR
BLUE
AMBER
OFF

LG Flatron M1717A Specifications

General

Brand	LG
Model	Flatron M1717A
Category	Monitor
Language	English
