LG Flatron W2284F User Manual

TIMING CHART
- 8 -
Copyright 2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
MODE
CLASSI
FICATION
Polarity
DOT
CLOCK
[MHz]
Frequency
[kHz]/ [Hz]
Total
Period
(E)
Display
(A)
Front
Porch
(D)
Sync.
(C)
Back
Porch
(B)
Resolution
H(Pixels) - 31.468 900 720 18 108 54
1
V(Lines) +
28.321
70.08 449 400 12 2 35
720 X
400
H(Pixels) - 31.469 800 640 16 96 48
2
V(Lines) -
25.175
59.94 525 480 10 2 33
640 x
480
H(Pixels) - 37.5 840 640 16 64 120
3
V(Lines) -
31.5
75 500 480 1 3 16
640 x
480
H(Pixels) + 37.879 1056 800 40 128 88
4
V(Lines) +
40.0
60.317 628 600 1 4 23
800 x
600
H(Pixels) + 46.875 1056 800 16 80 160
5
V(Lines) +
49.5
75.0 625 600 1 3 21
800 x
600
H(Pixels) - 48.363 1344 1024 24 136 160
6
V(Lines) -
65.0
60.0 806 768 3 6 29
1024 x
768
H(Pixels) - 60.123 1312 1024 16 96 176
7
V(Lines) -
78.75
75.029 800 768 1 3 28
1024 x
768
H(Pixels) +/ - 67.500 1600 1152 64 128 256
8
V(Lines) +/ -
108.0
75.000 900 864 1 3 32
1152 x
864
H(Pixels) + 63.981 1688 1280 48 112 248
9
V(Lines) +
108.0
60.02 1066 1024 1 3 38
1280 x
1024
H(Pixels) + 79.976 1688 1280 16 144 248
10
V(Lines) +
135.0
75.035 1066 1024 1 3 38
1280 x
1024
H(Pixels) + 64.674 1840 1680 48 32 80
11
V(Lines) -
119
59.883 1080 1050 3 6 21
1680 x
1050
H(Pixels) - 65.290 2240 1680 104 176 280
12
V(Lines) +
146.25
59.954 1089 1050 3 6 30
1680 x
1050
A
B
C
D E
F
Video
Sync
