SPECIFICATIONS
Copyright 2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. LCD CHARACTERISTICS
Type : TFT Color LCD Module
Active Display Area : 26 inch (756.228mm) diagonal
Pixel Pitch : 0.2505 (H) x 0.2505 (V)
Color Depth : 16,777,216 colors
Size : 677.30 (H) x 436.80 (V) x 42.30(D)
Electrical Interface : LVDS
Surface Treatment : Anti-Glare, Hard-coating(3H)
Operating Mode : Normally White
Backlight Unit : 4 CCFL
2. OPTICAL CHARACTERISTICS
2-1. Viewing Angle by Contrast Ratio ≥ 5
Left : -80°(Typ) Right : +80°(Typ)
Top :+80°(Typ) Bottom : -80°(Typ)
2-2. Luminance : 180(typ) (Typ.
30) -sRGB
: 200(min), 350(Typ), 400(max)
(Full white pattern, 0.7V)-6500K
: 150(min), 250(Typ), 350(max)
(Full white pattern, 0.7V)-9300K
: 75%(min), 80%(typ)
2-3. Contrast Ratio : 500(Min), 1000(Typ)
DFC->5000:1(Typ)
3. SIGNAL (Refer to the Timing Chart)
3-1. Sync Signal
• Type : Separate Sync, SOG, Digital
3-2. Video Input Signal
1) Type : R, G, B Analog
2) Voltage Level : 0~0.71 V
a) Color 0, 0 : 0 Vp-p
b) Color 7, 0 : 0.467Vp-p
c) Color 15, 0 : 0.714Vp-p
3) Input Impedance : 75Ω
3-3. Operating Frequency
Horizontal(Analog) : 30 ~ 83kHz
Horizontal(Digital) : 30 ~ 83kHz
Vertical : 56 ~ 75Hz
4. Max. Resolution
D-sub Analog : 1920 x 1200@60Hz
Digital : 1920 x 1200@60Hz
5. POWER SUPPLY
5-1. Power : AC 100-240V~, 50/60Hz , 0.8A
5-2. Power Consumption
6. ENVIRONMENT
6-1. Operating Temperature : 10°C~35°C (50°F~95°F)
(Ambient)
6-2. Relative Humidity : 10%~80% (Non-condensing)
6-3. MTBF : 50,000 HRS with 90% Confidence
Lamp Life : 50,000 Hours(Min)
7. DIMENSIONS (with TILT/SWIVEL)
Width : 601.9 mm (23.70'')
Depth : 270.2 mm (10.64'')
Height : 463.2 mm (18.24'')
8. WEIGHT (with TILT/SWIVEL)
Net. Weight : 12.3 kg (27.12 lbs)
Gross Weight : 15.4 kg (33.96 lbs)
MODE
POWER ON (NORMAL)
STAND-BY
SUSPEND
DPMS OFF
POWER S/W OFF
H/V SYNC
ON/ON
OFF/ON
ON/OFF
OFF/OFF
-
POWER CONSUMPTION
less than 110W(typ)
130W (USB Full load)
less than 1 W
less than 1 W
less than 1 W
less than 1 W
LED COLOR
BLUE
AMBER
AMBER
AMBER
OFF
VIDEO
ACTIVE
OFF
OFF
OFF
-
