4.11. Internal pressure
- Confirm whether is nomal or not when between power
board's ac block and GND is impacked on 1.5kV(dc) or
2.2kV(dc) for one second.
4.12 Option data setting (SVC OSD setting)
(1) Tool Option
*M198WA-BMH- Tool Option 7809
*M208WA/M228WA-BMH Tool Option 7810
* Area Option (M198WA/M208WA/M228WA-BMH)
Change by suffix
: Area Option : South America - S.Am
No. Item Condition Remark
1 2HR-OFF 1 0 : 2 Hour off option -OFF
1 : 2 Hour off option -ON
2 FACTORY-MODE 0 0 : EEPROM Write Protection On
1 : EEPROM Write Protection Off
3 CHANNEL-MUTE 1
RAM Delay
1 Clock Phase 7
2 DQS0 Phase 2
3 DQS1 Phase 2
4 DQS2 Phase 2
5 DQS3 Phase 2
Power Off History
1 Last Power 0
2 Remocon 0
3 Key 0
4 Sleep Timer 0
5 RS232 0
6 Off Timer 0
7 Auto Off 0
8 2Hour Off 0
9 Reset 0
ETC
1 DFC Control 1
2 Exit Key 0
3 PWM DIM 255
4 Dimming Ctl. 255
5 DEBUG ON 0
6 UART ON 3
7 AGC TAKEOVER 16
8 AGC EData 0
9 AGC BData 0
10 VID Lev 96
11 SOG Level 4
M198WA-BTH REMARK
Resolution 1 WXGA+
Module 0
TV 1
VIDEO 1
COMPONENT 1
PC-RGB 1
DVI 1
HDMI 0
M208WA-BMH / M228WA-BMH REMARK
Resolution 2 WSXGA
Module 0
TV 1
VIDEO 1
COMPONENT 1
PC-RGB 1
DVI 1
HDMI 0
