5. Adjustment Command
5.1. Adjustment Commands(LENGTH=84)
5.2 EEPROM DATA READ
(1) Signal Table
(2) Command Set
* Purpose : To read the appointment Address of
E2PROM by 128(80h)-byte
5.3. E2PROM Data Write
(1) Signal Table
LEN : 84h+Bytes
CMD : 8Eh
ADH : E2PROM Slave Address(A0,A2,A4,A6,A8), Not
00h(Reserved by BufferToEEPROM)
ADL : E2PROM Sub Address(00~FF)
Data : Write data
(2) Command Set
* Purpose
1) EDID write : 16-byte by 16-byte, 8 order (128-byte)
write(TO “00 – 7F” of “EEPROM Page A4”).
2) FOS Default write : 16-mode data (HFh, HFl, VF, STD,
HP, VP, Clk, ClkPh, PhFine) write.
3) Random Data write : write the appointment Address of
E2PROM.
5.4. VRAM Read
1) Send CMD(70h) to read Video RAM value from MICOM
And save its value to 128-Bytes Buffer(Common Buffer
for the use of EDID)
2) Delay 500ms ( Time to Wait and Read Video RAM from
MICOM)
3) Be transmitted the contents of MICOM’s 128-bytes
Buffer to PC. (128th Data is the CheckSum of 127-bytes
data : That’s OK if the value of adding 128-bytes Data is
Zero)
FACTORY ON E0 00 00 Factory mode on
FACTORY OFF E2 00 00 Factory mode off
EEPROM ALL INIT. E4 00 00 EEPROM All clear
EEPROM Read E7 00 00 EEPROM Read
EEPROM Write E8 00 data EEPROM Write by some
values
COLOR SAVE
(R/G/B cutoff, Drive, EB 00 00 Color Save
Contrast, Bright)
H POSITION 20 00 00 – 100 They have different range
V POSITION 30 00 00 – 100 each mode, FOS Adjustment
CLOCK 90 00 00 – 100
PHASE 92 00 00 – 100
R DRIVE 16 00 00 – FF Drive adjustment
G DRIVE 18 00 00 – FF
B DRIVE 1A 00 00 – FF
R CUTOFF 80 00 00 – 7F Offset adjustment
G CUTOFF 82 00 00 – 7F
B CUTOFF 84 00 00 – 7F
BRIGHT 10 00 00 – 3F Bright adjustment
CONTRAST 12 00 00 - 64 Luminance adjustment
AUTO_COLOR_ F1 00 02 Auto COLOR Adjustment
ADJUST
CHANGE_COLOR F2 00 0,1,2,3 0: COOL
_TEMP 1: NORMAL
2: WARM
3: USER
FACTORY_DEFAULT F3 00 00 Factory mode off
& II_SW is “1”
& Input change to “ TV”
AUTO_INPUT F4 00 0,1,2,4 0 : TV
CHANGE 1 : AV1
2 : AV2
3 : Component
4 : RGB
5 : DVI
ADR VAL Description
CMD
(hex)
Adjustment Contents
