2.RELAYASSY(PTCANDOLP)
L N
T
3 2
2
M
C
SM
C
S
YES
NO
Normaloperationof
Compressoris
impossibleorpoor.
SeparatetheRelayAssy
fromCompressorand
measuretheresistance
betweenMandSwitha
TesterorWhistoneBridge.
(Figure21)
SeparatetheRelayAssy
fromtheCompressorand
checktheresistancevalue
betweentwoterminalsof
OLPwithaTester.
Observationvalueis
220V/50Hz:22Ω ±30%
115V/60Hz:6.8Ωｱ30%
240V/50Hz:33Ω ±30%
127,220V/60Hz:
22Ω±30%
Theresistancevalueis0
orserveralhundredsΩ.
Thevalueis
∞
.
Checkanother
electriccomponents.
ReplaceRelayAssy.
Checkanother
electric
components.
Replace
RelayAssy.
22erugiF12erugiF
